Advanced

Bluetooth BLE V5.0 Beacon RS485 Reader, Scanner, Observer for iBeacon, Altbeacon, Eddystone,TPMS

Model No.
S2B5485RI
Made in
Taiwan
Supplier
UCONNECT INTERNATIONAL CO., LTD.More About This Product
Request for Quotation

BLE V5.0 beacon scanner for all BLE beacon and report format

Key Features

Bluetooth BLE V5.0 Beacon RS-485 Reader

Internal Antenna

Model: S2B5485RI
Tag type for the iBeacon, Eddystone, AltBeacon, Uconnect beacon format
 The reader will read the BLE beacon tag and report the
packet via RS-485 interface. The reader will filter the iBeacon,
Eddystone, Altbeacon or Uconnect Tag. The DIP switch will
select the type of reader. The packet include the reader ID
which will identify the position information.

Applications:
1. Uconnect Active RFID for RTLS applications
2. iBeacon, Eddystone, Altbeacon beacon filter
3. The packet information include the reader ID, Beacon ID
and RSSI value

1. COM port: 9,600 bps,8 data bits,One stopbit,None parity,w/o flow control
2. Range: 50 m ,in open space for reference only
3. Bluetooth BLE V5.0
4. RS-232 Interface: D_SUB 9-pin Male
5. Frequency: 2.400 to 2.4835 GHz
6. Tx. Power: Max. 4 dBm
7. Rx. Sensitivity: -89 dBm typical
8. Power Supply: 5~40 VDC, 1A Max
9. Current Consumption: up to 30 mAh
10. Operation Temperature: –40 °C to +85 °C
11. Dimensions: 81.6 mm (L) x 31.75 mm (W) x 17 mm (H)
12. Internal Antenna Gain: max. 2 dB

BLE Beacon filter: iBeacon, Eddystone, AltBeacon, Uconnect
All DIP switch is “0” by default.
Tag type is "1": Uconnect Tag
Tag type is "2": iBeacon
Tag type is "3": Eddystone
Tag type is "4": Altbeacon

Remark: The adapter support several kinds of beacon format, please check the user manual.

Example:
$1,00A05053849D,1,00A050172A2C,30,0,0,,-71#
$2,00A05053849D,0,58E72F0CEF88,0,0,0,0,-48#
$3,00A05053849D,0,772BB24ADC36,0,0,0,0,-48#
$4,00A05053849D,0,012AC345EB45,0,0,0,0,-49#

DIP No. 1 is set to “1” (On): Raw packet data
Prefix: “$”
Raw packet data is between “$” and “CR”
Suffix: Carriage Return
Example:
$1EFF0600010920008DC8BE90AEB3B032E0B9F89A0CCED9FFFAE3BDBFB2DB75
$0201061BFF570100F8398F0A43BE1D146A75669AC8FB3A7601E1917E545CAB
$1EFF0600010920008DC8BE90AEB3B032E0B9F89A0CCED9FFFAE3BDBFB2DB75
$1EFF060001092000111B6E4CE83EB1E445E8B104838CB749E14A8BE404CB4A

Default: All pin is “0”, Baud rate 9,600 bps., 8 Data bits, None parity, 1 Stop bit.

DIP No. 9 is set to “1” (On): The baud rate is 115,200 bps, 8 Data bits, None parity, 1 Stop bit.

The scanner will support the customized BLE beacon filtering or report format for your applications. Please contact sales@uconnect.com.tw


Package Contents:
1.  Bluetooth V5.0 BLE RS-485 Reader x 1 pc
2.  Mini USB power cable x 1 pc
3.  User manual x 1 pc
